EAN 4719331854645MODEL B760M H V2 1.0
// Motherboards · GIGABYTE
GB B760M H V2 / LGA1700
LGA1700 /Intel 12th and 13th Gen
99,66 €
● In stockGB B760 2xDDR5 4xSATA3 RAID HDMI DP 1xM2 GLAN 1xPCIEx16 1xPCIEx1
99,66 €
// Tech specs
ManufacturerGIGABYTE
ChipsetIntel® B760 Express Chipset
CPU supportLGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors;L3 cache varies with CPU
MemorySupport for DDR5 8000(O.C.) /7800(O.C.) /7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) /…
StorageChipset:;- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support);- 4 x SATA 6Gb/s connectors;RAID 0, RAID 1, RAID 5, an…
ExpansionCPU:;- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16;Chipset:;- 1 x PCI Express x1 slot, supporting PCIe 3.0 and running…
Form factorMicro ATX Form Factor; 24.4cm x 22.0cm
EAN4719331854645
ModelB760M H V2 1.0
▸ Full specifications▾ Full specifications
OSSupport for Windows 11 64-bit;Support for Windows 10 64-bit
LanRealtek® GbE LAN chip (1 Gbps/100 Gbps/10 Mbps)
USBChipset:;- 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header;- 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header);- 2 x USB 2.0/1.1 ports available through the internal USB header;Chipset+USB 2.0 Hub:;- 4 x USB 2.0/1.1 ports on the back panel
BIOS1 x 128 Mbit flash;Use of licensed AMI UEFI BIOS;PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
AudioRealtek® Audio CODEC;High Definition Audio;2/4/5.1/7.1-channel
ChipsetIntel® B760 Express Chipset
StorageChipset:;- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support);- 4 x SATA 6Gb/s connectors;RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
GraphicsIntegrated Graphics Processor-Intel® HD Graphics support:;- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz;* Support for DisplayPort 1.2 version and HDCP 2.3;- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz;* Support for HDMI 2.1 version and HDCP 2.3.;** Support for native HDMI 2.1 TMDS compatible ports.
// Compatibility
Motherboards · LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors;L3 cache varies with CPU
// Delivery & warranty
- ✓Genuine part
- ✓3-year warranty
- ✓Delivery across Bulgaria
