OtherOperating Temperature 40 °C
Weight2.032Kg
AC InputInput Voltage: 100V-240V;Input Current: 850W : 12A;Input Frequency: 47 – 63 Hz
DC OutputDC Output Voltage: +5V | +3.3V | +12V | -12V | +5Vsb;Total Output: 850W
ConnectorsATX 24 Pin Connector: 1;EPS 8 Pin Connector: 2;PCI-E 6+2 Pin Connector: 2;Molex 4 Pin Connector: 2;12VHPWR (12 + 4) Connector (600W): 1;SATA Connector: 6
Dimensions140 x 150 x 86 mm
Form factor850W: ATX 3.1
Power [Watts]850W: 1700W (*up to 200% of the PSU's rated power for 100μs)
Fan informationFan Size: 120 x 120 x 25mm;Fan Bearing: FDB;Fan Speed: 2400;MTBF: 100,000 hours
Safety and Environmental
